M'dziko lamagetsi, zingwe zina zimayenera kupita "kumwamba ndi pansi"-ziyenera kukhala zolimba-zolimba ngakhale kutentha kotentha kwa magawo a injini, pansi pa voteji yamphamvu yosalekeza ya ma inverter atsopano, komanso m'ma labotale ovuta kwambiri.UL3907ndi "msilikali wamkulu-wotentha kwambiri," kukhala ngwazi yosadziwika bwino m'mafakitale ndi magetsi atsopano chifukwa cha mphamvu zake zotha kupirira kutentha kwa madigiri 200 ndi 1100V high voltage. Lero, tikambirana nkhani yodziwika bwino ya "waya wamoto" uyu, ndikuwona momwe imawonekera kuchokera kumadzi am'madzi kuti athandizire mainjiniya kuthana ndi zowawa zenizeni.
Kodi UL3907 ndi chiyani kwenikweni? Ukadaulo wotsogola-wotsatira wa "UL"
UL3907 ndi mtundu wa AWM (Applied Wiring Material) single-waya wapakati wovomerezeka ndi Underwriters Laboratories (UL) molingana ndi miyezo ya UL758 ndi UL1581, yomwe imagwiritsidwa ntchito ngati mawaya amkati m'zida. Siwaya wamba wa PVC, koma "katswiri-wotentha kwambiri" wokhala ndi zotchingira mphira wa silikoni (SR) ndi m'chimake wopangidwa ndi ulusi woluka.
Wamba mawaya mosavuta kusungunuka ndi kugwa pa kutentha pamwamba 150 digiri , pameneUL3907imatha kupirira kutentha mpaka madigiri 200 ndi 1100V AC high voltage kwa nthawi yayitali. Izi zimapangitsa kuti zikhale zopikisana kwambiri m'magawo monga magalimoto amagetsi atsopano, kusungirako mphamvu za photovoltaic, ndi zipangizo zotenthetsera mafakitale. Chitsimikizo cha UL chimatanthawuza kuti yadutsa mphamvu yamagetsi, kuchedwa kwamoto, ndi mayeso okalamba, kuwonetsetsa chitetezo ndikuthandizira kutumiza bwino kumisika yapadziko lonse lapansi.
Tangoganizani: waya womwe umapirira "sauna" wa chipinda cha injini yagalimoto popanda kufewetsa kapena kufupika-kuzungulira-ndiwo mphamvu zolimba zedi!
Zovuta Kwambiri: Deta Imadzilankhula Yokha, Mphamvu Ndi Paintaneti
Mafotokozedwe a UL3907 ali ndi magawo ochititsa chidwi:
-
Mphamvu ya Voltage: 1100V AC, yogwira mosavuta-mawonekedwe amphamvu kwambiri.
-
Kutentha kwake: 200 digiri mosalekeza, kupitilira mawaya wamba.
-
Kondakitala: Lata-waya wopukutidwa kapena wopanda kanthu, wokwanira 16 AWG mpaka 600 kcmil, zomwe zimathandizira kufalikira kwamakono.
-
Insulation: High-rabara ya silikoni yotuluka bwino kwambiri, makulidwe amakongoletsedwa motengera momwe amafotokozera (mwachitsanzo, makulidwe a 12 AWG ndi pafupifupi 1.27mm).
-
Sheath: Synthetic fiber kapena glass fiber braid, kupititsa patsogolo kukana kwa abrasion ndi mphamvu zamanjenje.
-
Zina zazikulu: kusinthasintha kwabwino, kukana kwamafuta ndi mankhwala, kukana kwa conductor otsika, komanso kukhazikika kwamagetsi.
Mwachitsanzo, mtundu wa 12 Gauge uli ndi mainchesi akunja pafupifupi 5.1mm ndi kukana pafupifupi 5.53 Ω/km, kumapereka mphamvu zonse-zosatentha komanso zosavuta kuziyika ndi waya. Opanga nthawi zambiri amapereka matebulo atsatanetsatane, ndikusankha bwino monga kuyitanitsa chakudya.
Nkhondo Yeniyeni: Kodi UL3907 imawala kuti?
"Firewire" iyi sichidutswa chokongoletsera mu labu; imagwira ntchito m'magawo osiyanasiyana ovuta:
-
Nkhondo Yatsopano Yamphamvu: Ma inverters a Photovoltaic, mapaketi a batri osungira mphamvu, ndi zolumikizira zamkati zopangira milu. Imatumiza bwino mphamvu ngakhale kutentha kwambiri.
-
"Moyo" wagalimoto: Ma injini agalimoto amphamvu, -mabatire amphamvu kwambiri, ndi mawayilesi a injini; imakana kugwedezeka ndi kukalamba kutentha.
-
Industrial "Uvuni": Mkati zitsulo, mapulasitiki processing, ndi kuyanika zipangizo; pomwe mawaya wamba adasiya ntchito, akupitilizabe kugwira ntchito.
-
Zachipatala ndi Zamlengalenga: Zida zolondola komanso zoulutsira ndege, mapulogalamu omwe amafunikira kudalirika kwambiri komanso kutsika-utsi wokwanira.
-
Okonda Laboratory: -zida zoyezera kutentha kwambiri ndi zida zasayansi; imayendetsa mosavuta mikhalidwe yovuta kwambiri.
Akatswiri omwe adagwiritsa ntchito nthawi zambiri amati, "Pambuyo posinthaUL3907, kulephera kwa zida kunatsika kwambiri, ndipo ndalama zokonzera zidatsika kwambiri.
Kuyerekeza kwa UL3907 ndi mitundu ina ya UL: Tchati kuti muwone yomwe ili yoyenera kwa inu
| Chitsanzo | Adavotera Voltage | Kutentha kwake | Insulation Material | Sheath/Zinthu | Main Applications |
| UL3907 |
1100V |
200 digiri |
Silicone rabara + fiber kuluka | Chopangidwa ndi ulusi wagalasi / galasi, chitetezo champhamvu pamakina | Zida zamagetsi{{0}zopanda mphamvu komanso{1}}zotentha kwambiri, mphamvu zatsopano, katundu wolemetsa wamakampani |
| UL1007 |
300V |
80 digiri |
Zithunzi za PVC | PVC yowonda-yamipanda, yotsika mtengo | Mawaya amkati a zida wamba |
| UL1015 |
600V |
105 digiri |
Zithunzi za PVC | PVC yokulirapo, yosunthika kwambiri | Zida zamagetsi, waya wamkati wa mapanelo |
| UL3135 |
600V |
200 digiri |
Mpira wa silicone | Rabara ya silicone, popanda kuluka kowonjezera | Mawaya apamwamba-amatentha osasunthika, zofunika kusinthasintha kwambiri |
| UL3068 |
300V |
150 digiri |
Mpira wa silicone + woluka wagalasi | Kuluka kwa fiberglass | Mkati mwa zipangizo zotentha zapakati |
Kufananiza Chidule:
①UL3907imapambana bwino muchitetezo chamagetsi ndi makina, ndikupangitsa kuti ikhale yoyenera pazochitika zomwe zimafuna ma voltage apamwamba komanso kulimba kwamphamvu.
②UL3135 ilinso ndi malire a digirii 200 koma mphamvu yocheperako, kuyika patsogolo kusinthasintha ndikupangitsa kuti ikhale yoyenera kuyika ma cabling mumlengalenga-malo ochepera.
③Mndandanda wa PVC (UL1007/1015) ndi wokwera mtengo koma sungathe kupirira kutentha kwambiri komanso kupanikizika komanso sachedwa kukalamba.
Posankha, yang'anani zofunikira za kutentha ndi magetsi, kenako ganizirani kusinthasintha ndi bajeti.
Maupangiri Osankhira ndi Kagwiritsidwe: Kalozera Wopewera Mitsempha
Mukufuna kukulitsa mphamvu ya UL3907?
1. Choyamba, werengerani mphamvu yamagetsi, panopa, kutentha kwakukulu, ndi zinthu zachilengedwe.
2. Yang'anani pepala lachidziwitso kuti lifanane ndi AWG ndi makulidwe a insulation.
3. Sankhani UL-wopanga satifiketi yodalirika ndikupempha malipoti oyeserera.
4. Lolani utali wopindika wokwanira pakukhazikitsa kuti mupewe kuwonongeka kuchokera m'mbali zakuthwa.
Chenjezo: Musapitirire mitengo yovotera; sungani pamalo owuma, adzuwa-otetezedwa; kuunika momwe dongosolo lonse limagwirira ntchito ngati kuli kofunikira.
Kusankha "chingwe chamoto" choyenera kumalepheretsa zida kugubuduza.
Chifukwa cha kukwera kwa magetsi ndi luntha, kufunikira kwa-zingwe zogwira ntchito kwambiri ngati UL3907 kukuchulukirachulukira. M'tsogolomu, atha kuphatikizana ndiukadaulo wocheperako-pakhoma komanso kuyang'anira mwanzeru kuti zikhale zida zokhazikika m'malo opangira data, masiteshoni a 5G, ndi zida zatsopano zamagetsi. Aliyense amene amadziwa bwino-mawaya otentha kwambiri ali ndi kiyi yodalirika.
UL3907si waya wamba; ndi chida chachinsinsi cha injiniya motsutsana ndi malo owopsa. Kaya ndinu katswiri wa zamagetsi, wopanga zida zamakampani, kapena wokonda kufunafuna kudalirika kwambiri, "ngwazi{1}}yotentha kwambiri"yi ndi yofunika kuiganizira.
Chitetezo choyamba, kachitidwe kofunika kwambiri-loleni UL3907 ikuthandizeni kugwiritsa ntchito zida zanu zonse!
